Rheem ZR21K5E-PFV-800 Copeland Scroll ZRK5 Series Compressor, 1-5 HP, R-22, R-407C, Single-Phase, 21000 BTU

Product Description

The Rheem ZR21K5E-PFV-800 is a highly efficient Copeland Scroll Compressor designed for HVAC applications. This compressor operates using R-22 and R-407C refrigerants. It provides a cooling capacity of 21000 BTU, making it suitable for various residential and commercial applications.

• Single-phase design for easier installation.
• Operating voltage is 208 to 230 volts.
• Compact dimensions allow for versatile mounting options.

Product Highlights

This compressor features a durable scroll type mechanism and is designed for reliability and performance.

Product Information

Standard Information

• Manufacturer: Rheem
• Part Number: 052140

Technical Specifications

• Kick Start: 42-TO5
• Run Capacitor (µF/V): 35/370
• Start Capacitor Capacitance (µF/V): 88-106/330
• Start Relay Part Number: 42-25105-01
• Crankcase Heater Part Number: 44-17402-44
• Capacity BTU/hr: 21000
• Input Voltage (V): 208-230
• Locked Rotor Current (A): 56.0
• Max Continuous Current (A): 16.8
• Mounting Base Dimensions: 7-1/2 x 7-1/2 inches
• No of Phases: 1
• Overall Compressor Height: 15-5/16 inches
• Rated Load Current (A): 12.0
• Refrigerant: R-22
• Refrigerant Oil: Mineral (85-H2301)
• Soundwrap (Brinmar): 68-25217-10
• Frequency (Hz): 50-60
• Type: Scroll
• UPC: 662766429183
