Rheem UV12903 1 inch 3500W Stainless Steel Non-Resistored Screw-in Element LWD

Product Description

The Rheem UV12903 is a water heater element specifically designed for Rheem, Ruud, Friedrich, and Richmond water heaters. This element operates at 240 volts and provides a power output of 3500 watts. Constructed from stainless steel, it features a 1-inch screw fitting. The low-watt density (LWD) design ensures even heat distribution and enhances durability.

• Stainless steel construction offers long-lasting durability.
• Operates at 240 volts and 3500 watts.
• Direct replacement part for common water heater brands.

Product Highlights

This element is suitable for various water heating applications and guarantees reliable service in standard water heaters.

Product Information

Standard Information

• Manufacturer: Rheem
• Part Number: UV12903

Technical Specifications

• Voltage: 240V
• Wattage: 3500W
• Watt Density Classification: LWD
• Outer Sheath Material: Stainless Steel (Chromalox)
• Resistored: No
• Configuration: Foldback
• Element Diameter: 0.316 inches
• Mounting Type: Threaded
• Nominal Thread Size: 1 inch
• Threads per Inch: 11-1/2
• Thread Type Series Designation: NPSM
• Element Length - Flange to Tip: 13.9 inches
