RHEEM SP20110C Stainless Steel 4000W Non-Resistored Element LWD

Product Description

The Rheem SP20110C is a heating element designed for water heaters with a focus on efficiency. This model operates at 380 volts and provides 4000 watts of power. The stainless steel construction offers durability and longevity for various applications. It features a one-inch screw for secure installation into compatible water heaters. The foldback design promotes even heat distribution for improved performance.

• Converts electrical energy into heat for water heating
• Constructed from durable stainless steel
• Easy installation with a one-inch threaded screw

Product Highlights

This heating element provides reliable performance for water heating systems.

Product Information

Standard Information

• Manufacturer: Rheem
• Part Number: SP20110C

Technical Specifications

• Voltage: 380V
• Wattage: 4000W
• Watt Density Classification: LWD
• Outer Sheath Material: Stainless Steel (Incoloy)
• Configuration: Foldback
• Element Diameter: 0.316 inches
• Element Length (Flange to Tip): 13.48 inches
• Mounting Type: Threaded
• Nominal Thread Size: 1 inch
• Threads per Inch: 11-1/2
• Thread Type Series Designation: NPSM
• Hex Head Size - Across Flats: 1-1/2 inches
