Description

Product Description

The Rheem RCFZ2421MTANMC is a cased, multiposition N-coil evaporator coil for R-410A systems with TXV metering, rated at 2 ton (24,000 BTU/hr) cooling capacity. It features aluminum fins bonded to internally grooved aluminum tubing and copper sweat refrigerant connections. The coil includes two 3/4 in NPT condensate drain connections, Chatleff metering device connections, bi-directional airflow, and an AHRI certified design suitable for residential gas and oil furnace applications.

  • Multiposition N-coil design with TXV compatibility; rated 2 ton (24,000 BTU/hr) and 600-900 CFM
  • Aluminum fins bonded to internally grooved aluminum tubing with copper sweat refrigerant connections
  • Two 3/4 in NPT condensate drains, Chatleff TXV inlet/outlet and equalizer connections, bi-directional airflow

Product Highlights

Cased multiposition R-410A N-coil, TXV compatible, 2 ton (24,000 BTU/hr), aluminum fins with copper tubing, two 3/4 in NPT drain connections, AHRI certified

Product Information

Standard Information

  • Brand: RHEEM
  • Manufacturer Part Number: RCFZ2421MTANMC
  • Country of Origin: Mexico
Technical Specifications
Brand
Rheem
MPN
RCFZ2421MTANMC
Model
RCFZ2421MTANMC
Product Family
RCFZ
Series
RCFZ
Refrigerant
R-410A
Metering Device
TXV/TEV (thermostatic expansion valve)
Capacity
2 Ton
Cooling Capacity (BTU/hr)
24000
Tonnage
2
CFM
600-900
Coil Type
Cased
Coil Shape
N-Coil
Coil Fin Material
Aluminum
Coil Tube Material
Copper
Air Flow Direction
Multi-Position (bi-directional)
Drain Connection Quantity
2
Drain Connection Size
3/4 in NPT
Liquid Line Size (OD)
3/8 in
Liquid Line Fitting Type
Sweat or Braze
Suction Line Size (OD)
3/4 in
Suction Line Fitting Type
Sweat or Braze
Cabinet Width
21 in
Width
21 in
Height
20.5 in
Length
21.6875 in
Weight
64 lb
Drain Pan Material
High-grade heat-resistant corrosion-free thermal-set material
Compatible With UV
Yes
AHRI Certified
Yes
Coil Fin Corrosion Protected
No
Prop 65
Yes
Country of Origin
MEX
UPC
662021585838
MPN/Part Identifier Type
MPN
