Rheem ICM102B On Delay on Break Time Delay Relay Variable 0.03 - 10 min 0610

Product Description

The Rheem ICM102B is a reliable on delay on break time delay relay. It features a variable time delay setting ranging from 0.03 to 10 minutes, which is equivalent to one and a half to six hundred seconds. This relay is built for steady state with a current rating of one point five amps. The relay connects easily with quarter inch quick connects.

• Adjustable delay settings from 0.03 to 10 minutes
• 1.5A steady state current rating
• Compatible with 18-230VAC systems

Product Highlights

This product is ideal for HVAC applications where timing adjustments are necessary. Its design helps prevent short cycling by controlling the operation of systems effectively.

Product Information

Standard Information

• Brand: Rheem
• MPN: ICM102B

Technical Specifications

• Make Time Delay (minutes): 0.03 - 10
• Make Time Delay (seconds): 1.5 - 600
• Current Rating - Inrush (A): 15
• Current Rating - Steady State (A): 1.5
• Electrical Connections: 1/4 in. Quick Connects
• Time Delay Adjustment: Variable
• Frequency (Hz): 50/60
• Type: On Delay on Make
• Voltage Rating (VAC): 18-230
