Rheem as-104668-02 Evaporator Coil Drain Pan

Product Description

The RHEEM as-104668-02 is a tin-plated evaporator coil drain pan designed for use in residential and light commercial HVAC systems. The drain pan sits beneath the evaporator coil to collect condensate generated during normal cooling operation, directing moisture away from the air handler cabinet and preventing water damage or mold growth. The tin plating provides corrosion resistance in the consistently wet environment of an operating evaporator section. This part is installed by licensed HVAC technicians during routine maintenance, coil replacement, or when an existing drain pan shows signs of cracking, pitting, or leakage.

This drain pan is suited for split-system and packaged HVAC equipment where the evaporator coil assembly is serviced or replaced as part of a cooling system repair. It is sold as an individual unit and is intended as a direct OEM-style replacement component. Technicians working on equipment with failed or deteriorated drain pans will find this a straightforward swap within compatible Rheem equipment.

Key Features

• Tin-plated construction for corrosion resistance in wet condensate environments
• OEM replacement part ensuring proper fit within the evaporator coil assembly
• Sold individually for single-unit service calls
• Designed to collect and channel condensate away from cabinet components

Compatibility

Designed as an OEM-style replacement drain pan for Rheem evaporator coil assemblies. Refer to your equipment model documentation or a Rheem parts lookup to confirm fitment before ordering.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect power to the air handler or furnace and shut off the cooling system at the thermostat before beginning any coil or drain pan service. Ensure the primary and secondary condensate drain lines are clear and properly connected after the pan is seated. Follow applicable local mechanical codes when completing the repair.

Technical Specifications

• Material: Tin Plated
• Unit of Measure: Each

Standard Information

• Brand: RHEEM
• Manufacturer Part Number: as-104668-02
