RHEEM AP6614H-1 Rheem Element 240V 4500W Copper Non-Resistored MWD Flat Flange

Product Description

The Rheem Element AP6614H-1 is a flat flange heating element operating at two hundred forty volts and four thousand five hundred watts. This element is made of copper and is designed for medium watt density (MWD) applications, commonly found in various HVAC systems and electric water heaters. It efficiently converts electricity into heat, providing reliable water heating.

• Operates at 240V and 4500W
• Copper flange design
• Non-resistored MWD flat flange

Product Highlights

This heating element is built for energy efficiency and can help reduce electricity costs. Professional installation is advisable for optimal performance and warranty validation.

Product Information

Standard Information

• Type: Heating Element
• Brand: Rheem

Technical Specifications

• Watt Density Classification: MWD
• Input Voltage: 240V
• Wattage at 240V: 4500W
• Outer Sheath Material: Copper with Plating
• Resistored: No
• Configuration: Foldback
• Element Diameter: 0.316 inches
• Element Length - Flange to Tip: 11.56 inches
• Mounting Type: Flange
• Flange Hole Diameter - Four Places: 0.413 inches
• Flange Bolt Circle Diameter: 2.500 inches
