RHEEM AP12905 Rheem AP12905 1inch 5500W Stainless Steel Non-Resistored Screw-in Element LWD (240V)

Product Description

The Rheem AP12905 is a 1-inch, 5500W stainless steel non-resistored screw-in element designed for water heaters. Operating at 240V, it features durable construction from stainless steel (Incoloy). This element converts electrical energy into heat, effectively heating water in electric water heaters. The foldback configuration helps distribute heat efficiently, fitting most screw-in type water heaters.

• Wattage: 5500 Watts at 240V
• Voltage: 240V
• Material: Stainless Steel (Incoloy)

Product Highlights

This heating element is essential for efficient water heating in residential and commercial settings, ensuring reliability and long-lasting performance.

Product Information

Standard Information

• Product Type: Element
• Wattage at 240V (W): 5500

Technical Specifications

• Input Voltage (V): 240
• Watt Density Classification: MWD (Medium Watt Density)
• Outer Sheath Material: Stainless Steel (Incoloy)
• Configuration: Foldback
• Mounting Type: Threaded
• Nominal Thread Size: 1 inch
• Element Length - Flange to Tip (in.): 13.27
• Element Diameter (in.): .316
• Actual Thread Size - Outside Diameter (in.): 1-9/32
• Threads per Inch: 11-1/2
• Thread Type Series Designation: NPSM
• Hex Head Size - Across Flats (in.): 1-1/2
