Rheem AP10867QL-4 1inch 6000W Stainless Steel Resistored Screw-in Element LWD 208V

Product Description

The Rheem AP10867QL-4 is a one inch, six thousand watt stainless steel resistored screw-in element designed for water heaters operating at two hundred eight volts. It efficiently converts electrical energy into heat, raising the water temperature effectively. The resistored design aids in reducing mineral deposit buildup, enhancing the element's lifespan. This part is compatible as a direct replacement for various water heater brands, including Rheem, Ruud, and Richmond, and fits most water heaters utilizing screw-in elements.

• Operates at 208 volts and 6000 watts.
• Features a stainless steel construction.
• Designed with a 1-inch screw fitting.

Product Highlights

This element is suitable for a wide range of applications in water heating systems, providing reliable performance and durability.

Product Information

Standard Information

• Brand: Rheem
• MPN: AP10867QL-4

Technical Specifications

• Watt Density Classification: LWD
• Input Voltage: 208V
• Wattage at 208V: 6000W
• Watt Density at 208V: 84 W/sq. in.
• Cold Resistance: 7.20 ohms
• Outer Sheath Material: Stainless Steel (Incoloy)
• Resistored: Yes
• Configuration: Foldback
• Element Diameter: 0.316 in
• Element Length - Flange to Tip: 19.25 in
• Mounting Type: Threaded
• Actual Thread Size - Outside Diameter: 1-9/32 in
• Nominal Thread Size: 1 in
• Threads per Inch: 11-1/2
• Thread Type Series Designation: NPSM
• Hex Head Size - Across Flats: 1-1/2 in
• Weight: 1.23 lbs
• Dimensions: Length 20.1 in, Width 1.6 in, Depth 1.5 in
