Rheem AE-101128-31 Horizontal Furnace Coil Drain Pan

Product Description

The RHEEM AE-101128-31 is a horizontal drain pan designed for use with furnace coil assemblies in residential forced-air HVAC systems. It collects condensate generated during cooling operation, channeling moisture away from the air handler cabinet and surrounding structure. Measuring 23.9 inches in length, 17.3 inches in width, and 3.2 inches in height, the pan is sized to match the footprint of compatible Rheem furnace coil units. Installation is typically performed by a licensed HVAC technician during coil replacement or system maintenance. At 4.15 pounds, the pan is lightweight and straightforward to position within a horizontal coil installation.

This drain pan is intended for horizontal coil configurations in residential gas furnace and air handler systems. It is specified for use with the RCFL-HM3617CC furnace coil, making it a direct-fit replacement when the original pan shows signs of corrosion, cracking, or condensate leakage. Technicians servicing Rheem RCF3617 and RCF3621 series coil installations will find this pan appropriate for those horizontal applications.

Key Features

• Horizontal orientation matches coil drain pan geometry in compatible furnace coil assemblies
• Sized at 23.9 inches long by 17.3 inches wide by 3.2 inches deep for proper fitment
• Lightweight construction at 4.15 pounds simplifies handling during installation
• Direct OEM-style replacement designed to restore condensate containment in the original configuration
• Fits within horizontal coil system layouts without modification

Compatibility

Specified for use with the RCFL-HM3617CC Rheem furnace coil. Also referenced for RCF3617 and RCF3621 series furnace coil installations in horizontal configurations.

Installation Notes

Installation should be performed by a licensed HVAC technician. Shut off system power at the disconnect and set the thermostat to the off position before removing the existing drain pan. Verify the condensate drain line is clear and properly pitched before seating the replacement pan. Inspect the drain port alignment and ensure all connections are secure before returning the system to service.

Technical Specifications

• Type: Drain Pan, Horizontal
• Length: 23.9 inches
• Width: 17.3 inches
• Height: 3.2 inches
• Weight: 4.15 pounds

Standard Information

• Brand: RHEEM
• Manufacturer Part Number: AE-101128-31
