Rheem 61-105025-01 Txv R-410A 1.5-2 Ton Heat Pump

Product Description

The RHEEM 61-105025-01 is a thermostatic expansion valve (TXV) designed for R-410A refrigerant service in residential heat pump systems. The valve meters refrigerant flow into the evaporator coil, maintaining proper superheat across a range of operating conditions. It features 3/8-inch solder connections on both the inlet and outlet, making it a direct-fit component for sweat-in installation. Rated for 1.5- to 2-ton capacity, this TXV suits the lower-tonnage range of residential split-system heat pumps. Licensed HVAC technicians perform this replacement as part of refrigerant system service.

This valve is used on RHEEM RP14 series heat pump systems in the 1.5- to 2-ton capacity range. It is appropriate for residential split-system applications where R-410A is the system refrigerant. Typical installation scenarios include coil replacements, TXV failure diagnosis, and system efficiency restoration on existing RP14 equipment. Verify system tonnage and refrigerant type before ordering to confirm correct sizing.

Key Features

• Designed for R-410A refrigerant — not compatible with R-22 systems
• 3/8-inch solder inlet x 3/8-inch solder outlet connections for sweat-in installation
• Sized for 1.5- to 2-ton heat pump capacity range
• OEM replacement part for RHEEM RP14 series heat pumps
• Maintains proper superheat to protect the compressor under varying load conditions

Compatibility

Designed as an OEM replacement TXV for RHEEM RP14 series heat pump systems rated at 1.5 to 2 tons using R-410A refrigerant.

Installation Notes

TXV replacement must be performed by an EPA Section 608-certified HVAC technician. Recover all refrigerant from the system before opening any refrigerant circuit connections. Use a nitrogen purge during brazing to prevent oxidation scale inside the refrigerant circuit. After installation, leak-test all joints, pull a deep vacuum, and recharge the system to manufacturer specifications before returning the unit to service.

Technical Specifications

• Refrigerant: R-410A
• Capacity Range: 1.5-2 Ton
• Inlet Connection: 3/8 inches Solder
• Outlet Connection: 3/8 inches Solder
• Height: 4.35 inches
• Width: 4.55 inches
• Length: 24.6 inches
• Weight: 1.37 pounds

Standard Information

• Brand: RHEEM
• Manufacturer Part Number: 61-105025-01
