RHEEM 55-23148-22S Compressor

Product Description

The RHEEM 55-23148-22S is a compressor for air conditioning systems. This unit compresses refrigerants from a gas to a liquid state. It is a direct factory replacement reciprocating compressor that works on a single-phase power supply. The compressor is rated at 57,860 BTU.

• Compresses refrigerants for AC systems.
• Functions on 208-230 VAC single-phase power.
• Factory replacement for ease of installation.

Product Highlights

Designed specifically for efficient operation within AC systems.

Product Information

Standard Information

• Brand: Rheem Ruud
• MPN: 55-23148-22S

Technical Specifications

• Type: Reciprocating
• Refrigerant: R-22
• BTU Output: 57,860
• Input Voltage: 208-230 VAC
• Phase: Single
• Frequency: 60 Hz
• Run Capacitor: 65/370 uF/V
• Start Capacitor: 216-259/330 uF/V
• Rated Load Current: 17.8 A
• Max Continuous Current: 28.0 A
• Locked Rotor Current: 147 A
• Crankcase Heater Included: Yes
• Soundwrap (Brinmar): 68-25217-10
• Suction Line Location: 2
• Suction Line Height: 14 in.
• Suction Line Configuration: Stub Out
• Suction Line Size: 3/4 in.
• Discharge Line Location: 5
• Discharge Line Height: 4-1/8 in.
• Discharge Line Configuration: Up
• Discharge Line Size: 1/2 in.
• Overall Compressor Height: 15-7/8 in.
• Weight: 263 lbs
• Length: 41 inches
• Width: 4.8 inches
• Height: 47 inches
• Country of Origin: USA
