Rheem 47-21900-13 Limit Switch 25 Amp 230 V AC Manual Reset

Product Description

The Rheem 47-21900-13 is a robust limit switch designed for HVAC systems, ensuring safe and efficient operations. It seamlessly controls the temperature within industrial and commercial settings.

• Manual reset functionality enhances safety by requiring operator intervention after a trigger event.
• Robust construction made to withstand harsh environments with a temperature threshold of 150 degrees Fahrenheit.
• Easy installation with quick connect flange airstream mount system.

Product Highlights

This limit switch is crucial for maintaining optimal operating conditions within HVAC systems.

Product Information

Standard Information

• Brand: Rheem
• MPN: 47-21900-13
• Type: SPST, Normally Closed

Technical Specifications

• Power Rating: 25 Amp, 230 V AC
• Reset Type: Manual
• Dimensions: Length 2 inches x Width 1.63 inches
• Operating Temperature: 150 degrees Fahrenheit open, 31 degrees Fahrenheit close
• Mounting: 3/8 inch insertion depth
