Resideo VR8215S1214T/U Standard Dual Direct Ignition Gas Valve Single Stage

Product Description

The Resideo VR8215S1214T/U is a dual ignition gas valve designed for use in gas-fired appliances. It works with hot surface and direct spark ignition systems powered by twenty-four volts AC, with gas capacities ranging from thirty to four hundred fifteen cubic feet per hour.

• Features dual automatic valves for enhanced safety.
• Includes an adjustable servo regulator for consistent gas output pressure.
• Orientation-independent installation for versatile mounting options.

Product Highlights

This gas valve is suitable for various applications and allows for easy adjustments and wiring, making it straightforward for technicians to work with.

Product Information

Standard Information

• Product Type: Gas Valve
• Fuel Type: Natural Gas

Technical Specifications

• MPN: VR8215S1214T/U
• Voltage: 24V
• Body Pattern: Straight-Through
• Ignition Type: Direct Spark Ignition
• Max Capacity: 200000 BTU/h
• Min Capacity: 15000 BTU/h
• Inlet Connection Size: 1/2 in
• Outlet Connection Size: 1/2 in
• Operating Temperature Range: -40 °F to 175 °F
• Pressure Rating: 1/2 psi
• Provisions for ON-OFF Lighting Sequence
