Resideo VR8205Q2746T/U Gas Valve VR8205 2 Stage Direct Ignition Standard Opening 1.7/3.5 Inch WC 1/2 x 1/2 Inch NPT

Product Description

The Resideo VR8205Q2746T/U is a two-stage gas valve designed for direct ignition systems. This model operates under standard opening conditions with a pressure range of one point seven to three point five inches water column. It features a half inch by half inch NPT connection, making it suitable for various applications.

• Two-stage control for residential gas systems
• Operating temperature from -40 to 175 degrees Fahrenheit
• Designed for use with natural gas

Product Highlights

This valve offers dual automatic operation. It includes a manual valve and ensures safety with two automatic valves, one solenoid operated and one diaphragm operated. The design allows for easy access to adjustments and connections from the top.

Product Information

Standard Information

• Brand: Resideo
• Product Type: Two Stage Direct Ignition Gas Valve

Technical Specifications

• Pressure: 1/2 PSI
• Size: 1/2 x 1/2 Inch
• Temperature Range: -40 to 175 Degrees Fahrenheit
• Fuel Type: Natural Gas
• Application: Residential Gas Control System
• Shipping Weight: 3.000 LBS
• Width: 4-1/8 Inch
• Height: 4-5/8 Inch
• Depth: 2-11/16 Inch
