Resideo V8043E5061 3/4 Inch Sweat Connection Zone Valve 24V with Auxiliary Switch - Replacement V8043E5061

Product Description

The Resideo V8043E5061 zone valve is designed for optimal regulation of water flow within hydronic heating and cooling systems. This valve features a 3/4 inch sweat connection and is normally closed with an auxiliary switch for enhanced control.

• Suitable for controlling the flow of hot water.
• Features a manual opener for operation during power failures, returning to automatic operation upon power restoration.
• Supports 24V electrical connections with 18 inch leads.

Product Highlights

This zone valve is equipped with a robust cast iron body and brass internals, ensuring durability and efficiency in harsh conditions. Its design allows installation without disassembling the valve, facilitating a straightforward setup.

Product Information

Standard Information

• Brand: Resideo Braukmann
• MPN: V8043E5061

Technical Specifications

• Connection Type: Sweat
• Valve Size: 3/4 inch
• Maximum Operating Pressure: 125 psi
• Maximum Operating Temperature: 210 degrees Fahrenheit
• Electrical Specifications: 24V with 18 inch leads
• Body Material: Cast iron
• Internal Material: Brass
