Resideo V4043A1002 1/2 Flare Connection Zone Valve 120v

Product Description

The Resideo V4043A1002 is a 120V motorized zone valve designed for hydronic systems. This valve controls the flow of hot or chilled water and comes with a durable construction for easy installation. Ideal for heating and cooling applications, this valve operates in a normally closed position until activated. It includes features that allow for simple manual operation during power outages.

• Compact design for straightforward installation.
• Spring return to close action for reliable performance.
• Compatible with various hydronic systems.

Product Highlights

This valve is suitable for both residential and light commercial applications, providing efficient control of water flow in heating and cooling setups.

Product Information

Standard Information

• Brand: Resideo
• MPN: V4043A1002

Technical Specifications

• Voltage: 120V
• Pipe Size: 1/2 inch
• Body Pattern: Two-way, Straight-through
• Fluid Temperature Range: 40°F to 200°F
• Capacity: 3.5 Cv
• Maximum Close-off Pressure: 20 psi
• Electrical Connections: 18 inch leads
• Dimensions: 4 inches high x 4 11/16 inches wide x 2 3/8 inches deep
