Resideo TX-12 TX Potable Expansion Tank 4.4 Gallon

Product Description

The Resideo TX-12 Expansion Tank utilizes a butyl diaphragm for reliable pressure control in closed hydronic systems. Ideal for various commercial and industrial applications, this expansion tank safeguards against pressure surges and system damages.

• 4.4 gallon holding capacity to accommodate system needs without frequent maintenance interventions.
• Corrosion-resistant epoxy coating enhances durability and extends product life.
• Simplified installation with a 3/4 inch NPT external connection.

Product Highlights

Constructed from heavy-duty steel, the TX-12 maintains optimal system performance by effectively managing the expansion of water at high temperatures. Its non-metallic, non-corrosive polypropylene liner ensures that water remains uncontaminated, promoting system health and longevity.

Product Information

Standard Information

• Brand: Resideo
• MPN: TX-12
• Durable Construction: Steel with epoxy coating
• Capacity: 4.4 Gallons

Technical Specifications

• Diameter: 11 inches
• Height: 12.63 inches
• Connection Type: Male NPT
• Maximum Pressure: 150 psi
• Maximum Operating Temperature: 200°F
• Maximum Acceptance Volume: 3.2 Gallons
