Resideo TH6210U2001 2HT/1CL Prog 24V T6 Stat

Product Description

The Resideo TH6210U2001 is a 2-heat, 1-cool programmable thermostat engineered for precise temperature control and energy efficiency in residential and commercial HVAC systems. This digital, low-voltage thermostat features a user-friendly interface with a backlit LCD display, offering convenient management of indoor climate. It supports up to 2 Heat/1 Cool heat pump systems or 1 Heat/1 Cool conventional systems, operating on 24V AC power. The device allows for customized heating and cooling schedules to optimize comfort and reduce energy consumption.

• Easily create customized heating and cooling schedules for optimal comfort and energy savings.
• Navigate settings effortlessly with a large, backlit display and user-friendly buttons.
• Reduces energy costs by automatically adjusting temperatures based on programmed schedules.

Product Highlights

Programmable thermostat offering precise temperature control, energy savings, and an intuitive user interface for residential and commercial applications.

Product Information

Standard Information

• Brand: RESIDEO
• Manufacturer Part Number: TH6210U2001

Technical Specifications

• MPN: TH6210U2001
• Brand: Resideo
• Application: 24 VAC single-stage systems, gas, oil, electric warm air, hot water coil, electric hydronic, steam/gravity systems, 2H/1C Heat Pump with auxillary heat
• Thermostat Type: Programmable, Digital, Low Voltage
• Stages: Up to 2 Heat/1 Cool Heat Pump Systems, 1 Heat/1 Cool Conventional Systems
• Smart Home Integration: No
• Display Type: LCD Screen
• Display Size: 5.44 sq in
• Touchscreen: No
• Display Language: English
• Display Time Format: 24 Hour, 12 Hour (AM/PM)
• Modes of Operation: Heat, Cool, Emergency Heat, Off, Auto
• Program Type: 5-2 Programmable, 7-Day Programmable, 5-1-1 Programmable, Scheduled Disabled
• Energy Star Certified: No
• Alerts and Reminders: High Indoor Temperature, Low Indoor Temperature, Heat Pump Error, Battery Replacement, WiFi No Internet, Filter Change
• Heat-Cool Changeover: Auto, Manual
• Number of Batteries: 2
• Battery Life: 1 Year
• Battery Size: AA
• Battery Type: Alkaline
• WiFi: No
• Z-Wave: No
• RedLINK: No
• Sensor Type: Thermistor
• Differential Temperature: ± 1 °F, ± 0.5 °C
• Backlight Options: Adjustable
• Fan Function: Cycled, Continuous
• Clock Type: Year Clock
• Demand Response: No
• Running Current: 0.02 A to 1.0 A running
• Temperature Accuracy: 0.5°C, 1°F
• Electrical Connection Type: UWP Mounting System
• Interstage Differential Temperature: 1 to 1.5 °F Multistage only
• Mounting Type: UWP Wall Plate
• Power Supply Frequency: 60 Hz
• Storage Temperature Max: 120 °F, 49 °C
• Storage Temperature Min: -20 °F, -29 °C
• Mounting Location: Wall
• Fan Settings: Auto, On, Circ
• Interface: Button
• Electrical Ratings: 24V (20-30 Vac, 0.02-0.50A or 0.02-1.00A - varies by terminal)
• Power Method: Battery Only (2 x AA), Hardwired Only (terminals R & C) or Harwired with Battery Backup (terminals R + optional C)
• Terminal Designations: R, RC, C, W, O/B, W2-AUX, E, Y, Y2, G, L/A, K, S, and S
• Dual Fuel: No
• Setting Temperature Range: Heat 40°F - 90°F / Cool 50°F - 99°F
• Ambient Operating Conditions: 37 to 102°F, 5 to 90% RH, non-condensing
