Resideo T498A1778/U Electric Heat Thermostat 40°F - 80°F

Product Description

The Resideo T498A1778/U electric heat thermostat offers line voltage control specifically designed for electric heating systems. This non-programmable model utilizes a snap action switch, effectively activating the heating circuit when temperatures drop below the set range. It is constructed for vertical installation on standard outlet or junction boxes.

• Simple installation process with color-coded wiring.
• Durable Micro Switch mechanism for consistent performance.
• Includes range limit stops and a spare knob decal for easy calibration.

Product Highlights

This thermostat is ideal for managing heating in residential and commercial settings, providing reliable temperature control with a straightforward user interface.

Product Information

Standard Information

• Application: Electric Heat (Line Voltage), Heat Only
• Stages: 1 Heat

Technical Specifications

• Programmability: Non-Programmable
• User Interface: Mechanical
• Mount: Vertical
• Power Method: Hardwired
• Voltage: 120V, 240V, 208V, 277V
• Temperature Range: 40°F - 80°F
• Differential: 3°F
• Switch: SPST
• Amperage: 22, 19
• Wattage: 2280 to 6094
• Wiring: 6-inch Black and Red Leadwires
• Frequency: 60 Hz
• Height: 4.56 inches
• Width: 2.88 inches
• Depth: 1.9375 inches
• Approvals: CSA Listed, UL Listed
• Smart Home Integration: No
• Modes of Operation: Heating
• Energy Star Certified: No
• Warranty: 1 Year
