Resideo S89C1095/U Control Hot Surface Ignition Single Rod with 15 Second Lockout 24 Volt

Product Description

The Resideo S89C1095/U Control Hot Surface Ignition Single Rod is an effective component for automation in heating systems. It operates at twenty-four volts and features a fifteen-second lockout to enhance safety in various industrial applications.

• Fifteen-second lockout for added safety
• Twenty-four volt operation for reliable ignition
• Designed for industrial use

Product Highlights

This ignition control unit is built for industrial furnaces and boilers, ensuring quick and consistent start-ups. It is essential for systems utilizing hot surface ignition technology, making it a reliable choice for maintaining operational safety.

Product Information

Standard Information

• Brand: Resideo
• MPN: S89C1095/U

Technical Specifications

• Item Number: S89C1095/U
• Ignition Source: Line Voltage (120 VAC) Hot Surface Element (Norton Model 201)
• Ignition Sequence: Single trial for main burner ignition (then shut down and lockout)
• Ignition Trial Time: Six seconds
• Flame Failure Response Time: Two seconds @ 2.5 microamp
• Warm-Up Time: Thirty-four seconds, nominal
• Approvals and Standards: UL: Component Recognized: File No. MP268, Guide No. MCCZ2 | CGA Certified: 1029-ABl-6218 | AGA Certified: 20-20B1
