Resideo RP418A1107 Relay, Electric / Pneumatic, Surface Mounted, 120Vac, 50/60 Hz

Product Description

The Resideo RP418A1107 is a surface mounted electric and pneumatic relay designed to function in various applications. It can operate as a diverting relay, selector relay, or stop and bleed relay. This relay mounts easily in any position, making it versatile for different setups.

• Compatible with both lead wires and junction boxes.
• Supports line or low voltage configurations.
• Constructed from Valox 420 plastic and corrosion-resistant metal.

Product Highlights

Reliable relay for HVAC systems with easy mounting and operational flexibility.

Product Information

Standard Information

• Manufacturer: Resideo
• MPN: RP418A1107

Technical Specifications

• Type: Electric / Pneumatic Relay
• Power Supply: 110 Vac @ 50 Hz, 120 Vac @ 60 Hz
• Dimensions: 2-7/8 H x 3-13/16 W x 1-1/4 D
• Frequency: 50/60 Hz
• Maximum Operating Pressure: 50 psi
• Air Connection: Barbed fitting for 1/4 O.D. plastic tubing
• Airflow Usage: 0.42 scfm at 20 psi supply with 1 psi pressure drop
• Ambient Temperature Range: 0°F to 100°F (-18°C to +38°C)
• Operating Humidity Range: 5% to 95% RH
• Electrical Connection: Junction box and 15 leads
