Resideo MS8105A1030 Honeywell damper and valve actuator 8 VA (95 degrees stroke)

Product Description

Resideo MS8105A1030 is a damper and valve actuator for modulating and on-off control. It operates on 24 VAC, 50/60 Hz, consumes 8 VA, and uses a brushless DC motor to deliver a 95 degrees stroke with 44 in-lb torque and a 45 second actuation time. The unit includes screw terminal connections, a self-centering shaft adapter for CW/CCW rotation, and a NEMA 2/IP54 enclosure rated for -22 to 149 degrees F.

• Operates on 24 VAC, 50/60 Hz and consumes 8 VA with brushless DC motor
• Provides 95 degrees stroke, 44 in-lb torque and 45 second actuation
• Screw terminal connection, self-centering shaft adapter, NEMA 2/IP54 enclosure

Product Highlights

Modulating and on-off control actuator with 95 degrees stroke, 44 in-lb torque, and NEMA 2/IP54 enclosure

Product Information

Standard Information

• Brand: RESIDEO
• Manufacturer Part Number: MS8105A1030

Technical Specifications

• Brand: Resideo
• MPN: MS8105A1030
• Series: MS Series
• Input Voltage: 24 VAC, 50/60 Hz
• Power Consumption: 8 VA
• Electrical Connection: Screw terminal
• Actuation Time: 45 seconds
• Material: Aluminum
• Torque: 44 in-lb
• Noise Driving: 70 dBA
• Noise Holding: 20 dBA
• Operating Temperature: -22 to 149 degrees F
• Enclosure Rating: NEMA 2 / IP54
• Dimensions: 7.5 x 3.625 x 3.125 inches
• Action: Modulating and on-off control
• Motor Type: Brushless DC motor
• Mounting Type: Direct mounting
• Shaft Adapter: Self-centering
• Rotation: Clockwise and counterclockwise shaft rotation
• Stroke: 95 degrees
