Resideo L4081B1096 High Limit and Circulator Aquastat Controller 10 F Differential

Product Description

The Resideo L4081B1096 Aquastat Controller is designed for precision temperature control in heating systems. Crafted by Resideo, a leader in HVAC solutions, this controller integrates dual functionality with high limit protection and circulator control capabilities.

• Integrated dual SPST switches for independent temperature adjustments.
• Easy installation with single sensing element and push-in terminals.
• Equipped with a fixed 10 F differential for accurate temperature management.

Product Highlights

This advanced aquastat controller offers adjustable settings for both high and low limits, ensuring optimal performance across a temperature range of 110 F to 240 F. With its robust design, it suits various HVAC applications, ensuring safety and efficiency.

Product Information

Standard Information

• Brand: Resideo
• MPN: L4081B1096

Technical Specifications

• Temperature Range: 110 F to 220 F (Low Limit), 130 F to 240 F (High Limit)
• Differential: 10 F fixed
• Electrical Ratings: 8A @ 120 Vac, 5.1A @ 240 Vac
• Mounting: Horizontal
• Dimensions: 3.875 inches high x 4.125 inches wide x 2.75 inches deep
• Switching Action: SPST for High Limit and Circulator
