Resideo L4008E1305 High Limit Remote Bulb Aquastat Manual Reset 100 to 240 Degree Fahrenheit

Product Description

The Resideo L4008E1305 High Limit Remote Bulb Aquastat provides efficient and reliable temperature regulation for heating systems. This manual reset aquastat operates within a temperature range of 100 to 240 degrees Fahrenheit, ensuring optimal performance.

• Quick response to temperature changes with remote temperature sensing element.
• Visible control point scale and external adjustment for easy setup.
• Compatible with both horizontal and vertical mounting configurations.

Product Highlights

Equipped with a totally enclosed Micro Switch+ snap-acting switch for safety, the Resideo L4008E1305 adjusts easily through an external screw, supporting both vertical and horizontal installations. Its rugged case design mounts securely and offers a long service life.

Product Information

Standard Information

• Brand: Resideo Braukmann
• MPN: L4008E1305

Technical Specifications

• Bulb Size: 3/8 inch x 2 7/8 inch copper
• Capillary Length: 66 inches
• Switching Action: SPST, contacts break on temperature rise
• Operating Temperature Range: 100°F to 240°F
• Electrical Ratings: 8A at 120 Vac, 5.1A at 240 Vac
• Differential Temperature: Manual Reset
• Maximum Ambient Temperature: 150°F
• Case Dimensions: 5 5/8 inches high x 2 inches wide x 2 1/8 inches deep
