Resideo DS06-101-LF DS06 DialSet® 3/4 in. 250 psi Bronze FNPT Pressure Regulating Valve Body (Lead Free)

Product Description

The Resideo DS06-101-LF is a pressure regulating valve designed to maintain a consistent outlet pressure in various settings. This valve is made from bronze and includes a 3/4-inch FNPT connection. It is suitable for both commercial and industrial applications where controlling water pressure is critical.

• 3/4-inch NPT connection
• Pressure adjustment range of 25 to 90 PSI
• Suitable for non-union applications

Product Highlights

This valve is designed for various applications including irrigation and process control systems. Its dial-set feature allows for easy adjustments without needing a separate gauge. This functionality aids in efficient system management.

Product Information

Standard Information

• Brand: Resideo
• MPN: DS06-101-LF

Technical Specifications

• Item Number: DS06-101-LF
• Max Inlet Pressure: 250 PSI
• Pressure Range: 25 to 90 PSI
• Operating Temperature: 140°F Maximum
• Reducing Ratio: 10:1 Maximum
• Connection Type: Female NPT
• Dimensions: 5.25 inches High x 3.375 inches Long
• Gauge Tap: 1/4 in. NPT
