Resideo DPL1030A5014/U 1 pole 24 vac PowerPro definite purpose contactor

Product Description

The RESIDEO DPL1030A5014/U is an electromagnetically-operated Definite Purpose Contactor, featuring a 1 Pole with shunt configuration and a 24 Vac coil. Designed for switching induction motors, it operates at 50 Hz or 60 Hz. This PowerPro contactor is compliant with A2L refrigerants and utilizes box lug with quad .250'' quick connect terminals for electrical connections, ensuring reliable performance in various applications.

• Compliant with A2L refrigerants.
• Meets ARI-780 Standard at started ratings (500,000 cycle mechanical life, 200,000 cycle electrical life and 10,000 cycle recycle life).
• Silver cadmium oxide contacts provide long life under demanding duty cycles.

Product Highlights

Low profile design allows for more wiring room and features multiple mounting holes and slots for convenient, interchangeable installation.

Product Information

Standard Information

• Brand: RESIDEO
• Manufacturer Part Number: DPL1030A5014/U

Technical Specifications

• Application: PowerPro Definite Purpose Contactor
• Approvals and Standards: UL Recognized Component: File No. E220475/ E59779, Guide No. LZGH2, LZGH8; CSA Certified: File No. LR6535; CE Compliant; RoHS Compliant; ARI 780/790
• Coil Voltage: 24 V ac
• Coil Connection Size: 1/4 in
• Coil Connection Type: Quick Connect
• Number of Poles: 1 Pole with shunt
• Operating Frequency: 50 Hz, 60 Hz
• Electrical Connection Type: Box lug w/ quad .250'' quick connect terminals
• Switch Action: SPST
• Ambient Operating Temperature Range: -13 °F to 158 °F (-25 °C to 70 °C)
• Suitable For Use With: Induction Motors
• Contact Rating: 32 A at 240, 277, 480, 600 V, 40 A at 240, 277, 480, 600 V
