Resideo camwe-wo VX3 Hd Outdoor Camera 2MP Wifi Poe

Product Description

The RESIDEO camwe-wo is a 2MP Full HD outdoor security camera designed for reliable video surveillance in residential and light commercial connected-home systems. Built around a 1920 x 1080 pixel image sensor with Wide Dynamic Range (WDR), it delivers crisp live and recorded video in both day and low-light conditions using three 850nm infrared LEDs. The camera supports dual-band WiFi (2.4 GHz and 5 GHz) and Power over Ethernet (PoE 802.3af, Class 3), giving installers flexible network connectivity options. It is housed in UV-resistant material rated IP66 for weather resistance and operates across an extreme temperature range of -40 degrees F to 122 degrees F.

This camera is intended for outdoor installation in residential connected-home security systems. It integrates with the PROA7PLUS ProSeries panel for on-screen video streaming. Advanced event detection distinguishes between people, packages, vehicles, and animals, reducing false alerts. The camera also supports a deterrent spotlight and siren for active response. It is installed by security system technicians and integrators in locations requiring perimeter monitoring, driveway coverage, or entry-point surveillance. Cloud storage plans support up to 30 days of clip history.

Key Features

• 2MP Full HD resolution at 1920 x 1080 pixels with WDR for balanced exposure in high-contrast lighting
• Dual-band WiFi (2.4 GHz and 5 GHz, 802.11ac 2x2) plus PoE (802.3af, Class 3) for flexible installation
• IP66-rated weather-resistant housing with UV-resistant material; rated -40 degrees F to 122 degrees F
• Three 850nm IR LEDs with color night vision and on-event color night vision modes
• Advanced event detection for people, packages, vehicles, and animals
• Two-way audio and built-in deterrent spotlight and siren
• BLE 5.0 for commissioning; integrates with PROA7PLUS ProSeries panel for on-screen streaming

Compatibility

Integrates with the PROA7PLUS ProSeries security panel for on-screen video streaming. Suitable as an outdoor camera in connected-home security systems supporting WiFi or PoE network-connected cameras.

Installation Notes

Installation should be performed by a licensed security system technician familiar with low-voltage wiring and network configuration. When using PoE, verify the switch or injector meets 802.3af Class 3 requirements before connecting. For DC power, use a 12V/1A supply meeting local electrical codes. Mount using the included brackets and hardware; ensure the mounting surface is rated to support the camera weight and provides a weatherproof seal around any wall penetrations.

Technical Specifications

• Resolution: 2MP Full HD, 1920 x 1080 pixels
• Power Supply: PoE 802.3af Class 3 or DC 12V/1A
• WiFi: 2.4 GHz and 5 GHz, 802.11ac 2x2
• Bluetooth: BLE 5.0
• Night Vision: Three 850nm IR LEDs
• Audio: Two-way audio
• Protection Class: IP66 weather resistant
• Operating Temperature: -40 degrees F to 122 degrees F (-40 degrees C to 50 degrees C)
• Ambient Relative Humidity: 10% to 95% non-condensing
• Product Height: 5.04 inches
• Product Width: 3.32 inches
• Product Weight: 0.73 pounds (11.64 oz)
• Color: White
• Storage: 30-day plan stores up to 1,500 clips; 7-day plan stores up to 350 clips
• Use Location: Outdoor
• Includes: VX3 camera, mounting hardware, mounting brackets, quick installation guide

Standard Information

• Brand: RESIDEO
• Manufacturer Part Number: camwe-wo
