RESIDEO BRAUKMANN VC6011ZZ00 3-way VC Actuator, On/Off switch, SPDT, 120 Vac

Product Description

The RESIDEO BRAUKMANN VC6011ZZ00 is a three-way valve actuator designed for effective control in heating and cooling systems. It operates using an On/Off SPDT switch and is compatible with various water types including cold, warm, and hot water. The compact design ensures efficient performance, making it ideal for applications in fan coil units, radiators, and convectors.

• Controls central heating and cooling systems, including fan coils.
• Enables tool-free replacement of internal components.
• Installation does not require draining the system.

Product Highlights

This actuator simplifies maintenance and is energy efficient, consuming minimal power.

Product Information

Standard Information

• Application: HVAC
• Control Signal: On/Off switch, SPDT

Technical Specifications

• Media Temperature (Max): 203 °F, 95 °C
• Supply Voltage: 120V
• Frequency: 50 Hz; 60 Hz
• Power Consumption: 6 VA
• Dimensions: 2.8 inches high x 3.7 inches wide x 2.7 inches deep
• Materials: Plastic housing
• Mounting: Direct Coupled
• Ambient Temperature Range: 32 °F to 150 °F, 0 °C to 65 °C
• Approvals: UL Recognized, CSA Certified, CE
• Environmental Rating: IP40, Double Insulated
• Stroke: 0.4 inches
• Timing: 6 seconds
• Compatible With: Cold, warm, and hot water applications
• For Use With: VC Series Valve
• Warranty: 1 Year
• Electrical Connections: Cable, 39 inches
• Operating Humidity Range: 5 to 95% RH, non-condensing
• Shipping Temperature Range: -40 °F to +150 °F, -40 °C to +65 °C
• Fail Safe Mode: Stays in place
• Cable: Molded strain relief
