Resideo Braukmann VC4613ZZ00 Actuator 230V SPST with Auxiliary Switch

Product Description

The Resideo Braukmann VC4613ZZ00/U is an actuator that integrates with VC series motorized zone valves. It is suitable for residential and light commercial heating and cooling systems. This on/off actuator utilizes a Single Pole, Single Throw (SPST) switching mechanism and includes an auxiliary switch. A one-meter electrical connection cable is included for installation.

• Operates as an on/off actuator with SPST switching.
• Includes an auxiliary switch and a one-meter electrical connection cable.
• Designed to work with VC series motorized zone valves for heating and cooling.

Product Highlights

This actuator controls hot and cold water flow and can handle a differential pressure for close-off up to 400 kPa. It emphasizes quiet operation and is easy to maintain, allowing for quick replacement of internal components without draining the system.

Product Information

Standard Information

• Brand: Resideo Braukmann
• MPN: VC4613ZZ00

Technical Specifications

• Actuator Voltage: 230V, 50-60Hz
• Power Consumption: 4VA during valve position changing
• Electrical Connection: 1m cable
• Differential Pressure for Close-Off (Max): 400 kPa
• Auxiliary Switch Rating: 1.0 A @ 250 V, 50-60 Hz (minimum 0.05 A @ 24 Vdc)
• Runtime: 6 seconds (on/off actuators)
• Actuator Electrical Rating: IP40
• Compatible Medium: Water or water-glycol mixture (max. 50% glycol content)
• Operating Temperature (Medium): 1 to 95 degrees Celsius, with peaks up to 120 degrees Celsius
• Ambient Temperature: max. 65 degrees Celsius
• Operating Pressure (System): max. 20 bar
