Resideo Braukmann T991A1061 Modulating Temperature Controller

Product Description

The Resideo Braukmann T991A1061 is a modulating temperature controller aimed at controlling the temperature of water or air in various settings, such as ducts and tanks. This device includes a remote sensing bulb along with a five-foot capillary tube for flexible installation of the sensing element. The design minimizes the impact of ambient temperature on the unit and its tubing. Users can easily read and adjust the setpoint through the cover, and the internal throttling dial allows for adjusting the proportional throttling range.

• Provides modulating control of water or air temperature.
• Features a remote sensing bulb with a five-foot capillary tube.
• Compensates for ambient temperature effects.

Product Highlights

The T991A1061 is reliable for HVAC applications that require precise temperature control.

Product Information

Standard Information

• Application: Provide modulating control of water or air temperature in ducts or tanks
• Type: Modulating Remote bulb

Technical Specifications

• Output Type: Analog
• Analog Output: One 135 Ohm Potentiometer
• Voltage: 24 Vac to 30 Vac
• Frequency: 50 Hz, 60 Hz
• Setpoint Temperature Range (F): 160 F to 260 F
• Maximum Operating Temperature (F): 280 F
• Throttling Range (F): 3 F to 30 F
• Capillary Length (ft): 5 ft
• Bulb Size (in.): 1/2 in. diameter x 4-3/16 in. long
• Sensor Element: Copper bulb
