Resideo Braukmann T822D1024 1 Heat Stage Thermostat

Product Description

The Resideo Braukmann T822D1024 is a non-programmable thermostat designed for heating in low voltage systems. It features reliable R and W terminals for straightforward installation. The vented cover enhances temperature sensing capabilities. The vertical mounting design allows it to be easily installed on a wall or outlet box. An integrated thermometer and setting scale on the face simplify temperature adjustments.

• Non-programmable for simple operation
• Suitable for single-stage heating control
• Vented cover for enhanced temperature accuracy

Product Highlights

This thermostat is ideal for those seeking an easy-to-use heating control solution in low voltage systems.

Product Information

Standard Information

• Brand: Resideo Braukmann
• MPN: T822D1024

Technical Specifications

• Application: Heating only control in low voltage systems
• Mounting: Vertical Mounting
• Changeover: None, Heat only
• Stages: 1 Heat
• Terminal Designations: R, W
• Switch Type: SPST
• Accuracy (F): 2 F
• Accuracy (C): 1 C
• Setting Temperature Range (F): 55 F to 95 F
• Electrical Ratings: 20 to 30 Vac
• Anticipator (heating): 0.18 to 1.0A Adj
• Currents (Heating): 0.18 to 1.0A @ 30 Vac/Vdc
• Sensor Element: Bimetal
