Resideo Braukmann T775U2006 Honeywell Special Stand Alone Remote Temperature Controller 24Vac or 120/240Vac

Product Description

The Resideo Braukmann T775U2006 is a remote temperature controller designed for both 24Vac and 120/240Vac systems. It features two SPDT relay outputs and supports two sensor inputs, with Sensor B designated for reset only. This controller is suitable for various applications including humidity and pressure control.

• Temperature range from -40 to 248 degrees Fahrenheit.
• Multiple output types including 2-10Vdc, 0-10Vdc, and 4-20mA.
• High accuracy of ±1 degree at 77 degrees Fahrenheit.

Product Highlights

Designed for flexibility and accuracy, this controller is ideal for HVAC systems that require precise temperature management.

Product Information

Standard Information

• Brand: Resideo Braukmann
• Type: Stand Alone Remote Temperature Controller

Technical Specifications

• Relay Outputs: 2 SPDT
• Sensor Input: 2
• Max Distance to Sensor: 1000 feet
• Accuracy: ±1 degree @ 77 degrees Fahrenheit
• Throttling Range: 1-150 degrees Fahrenheit
• Differential Temperature: 1-150 degrees Fahrenheit
• Contact Ratings: 10 Amp @ 24Vac, 9.8 Amp @ 120Vac, 4.9 Amp @ 240Vac
• Pilot Duty: 125 VA @ 120Vac and 240Vac
