Resideo Braukmann T6051A1016 Heavy Duty Line Voltage Thermostat

Product Description

The Resideo Braukmann T6051A1016 is a heavy-duty line voltage thermostat for heating and cooling systems. This thermostat controls fan coils, fans, motor starters, valves, contactors, and circulator motors. It provides line voltage comfort control and is compatible with Q651A and B sub-bases for system and fan switching.

• Removable set point knob for tamper prevention
• Calibrated for accuracy at one thousand feet above sea level
• Suitable for a range of heating and cooling applications

Product Highlights

This thermostat is designed for effective temperature management in various systems. It offers a durable and reliable solution for HVAC needs.

Product Information

Standard Information

• Brand: Resideo Braukmann
• MPN: T6051A1016

Technical Specifications

• Type: Line Voltage, Heavy Duty, Heat/Cool
• Cover Type: Plastic, Vertical, Locking
• Voltage Rating: 120/240 Volt AC, 50/60 Hertz
• Current Rating: 22 Amp at 120 to 240 Volt AC
• Power Rating: 125 Volt Amp (Pilot Duty)
• Switch Type: SPDT
• Size: Three and one eighth inches Width x One and five eighth inches Depth x Five inches Height
• Approval: UL, CSA
• Setting Temperature Range: 46 to 84 Deg F
• Differential Temperature: One Deg F
• Application: Fan Coil, Motor Starter, Valve, Contactor, Circulator Motor
• Mounting Type: Horizontal/Vertical
• Differential: One Deg F, Fixed
