Resideo Braukmann ML6984A4000 Linear Valve Actuator

Product Description

The Resideo Braukmann ML6984A4000 is a self-contained, motorized valve actuator. It is designed for direct mounting onto V5011 two-way and V5013 three-way globe valves. This actuator operates with a linear stem between one half inch and one inch.

• Designed for direct mounting on globe valves.
• Microprocessor-based control for accurate positioning.
• Compact design for easy installation in tight spaces.

Product Highlights

Ideal for HVAC systems, the actuator provides reliable control of fluid flow in heating and cooling applications.

Product Information

Standard Information

• Brand: Resideo Braukmann
• MPN: ML6984A4000

Technical Specifications

• Control Type: 2-Position, Floating, SPDT
• Power Supply: 24 VAC or 28 VDC
• Torque: 160 lbf (710 N)
• Stroke Length: 0.5 in / 1 in (13 mm / 25 mm)
• IP Rating: IP54
• Operating Temperature: 32 °F to 130 °F (0 °C to 50 °C)
• Storage Temperature: -40 °F to 150 °F (-40 °C to 65 °C)
• Valve Compatibility: 1/2 to 3 in V5011/V5013/VGF
• Actuator Motion: Linear
• Actuator Type: Electric
