RESIDEO BRAUKMANN L4079B1033 Pressuretrol Limit Controller

Product Description

The RESIDEO BRAUKMANN L4079B1033 Pressuretrol Limit Controller is a limit switch that breaks electrical circuits when pressure reaches a set limit. It is versatile for applications involving steam, air, non-combustible gases, and fluids non-corrosive to stainless steel.

• Manual reset feature for safety
• Compatible with various media including steam and air
• Mountable with 1/4 inch NPT fitting

Product Highlights

This controller is essential for maintaining system safety and functionality.

Product Information

Standard Information

• Brand: RESIDEO BRAUKMANN
• MPN: L4079B1033

Technical Specifications

• Application: Provide limit control of steam, air, non-combustible gases or non-corrosive fluids
• Operating Range: 2 to 15 psi
• Maximum Diaphragm Pressure: 25 PSI
• Switch Operation: Manual reset, break on pressure rise
• Electrical Connections: Screw terminals
• Sensor Element: Stainless steel diaphragm
• Maximum Operating Temperature: 150 F (66 C)
• Mounting: 1/4 in. NPT female
