Resideo Braukmann 393690-14 Flange 3/4 inches Straight

Product Description

The Resideo Braukmann 393690-14 flange is a 3/4" straight flange. These direct ignition combination gas controls are used in gas-fired appliances with capacities up to 300 feet³/hour at 1 inch wc pressure drop [8.5 meters³/hour at 0.25 kPa] for natural gas. It includes a manual valve, two automatic operators, a pressure regulator, and a conduit cover.

• Direct ignition combination gas control
• Includes a manual valve, two automatic operators, and a pressure regulator
• Standard-opening model (VR4305M) ambient temperature range: -40° to 175° F [-40° to +79° C]

Product Highlights

The Resideo Braukmann 393690-14 flange is suitable for gas-fired appliances. It features a manual valve, automatic operators, and a pressure regulator.

Product Information

Standard Information

• Brand: RESIDEO BRAUKMANN
• Manufacturer Part Number: 393690-14

Technical Specifications

• Body Pattern: Straight-through
• Capacity (1/2 x 1/2): 240 feet³/hour [6.8 meter³/hour]
• Capacity (1/2 x 3/4): 270 feet³/hour [7.6 meter³/hour]
• Capacity (3/4 x 3/4): 300 feet³/hour [8.5 meter³/hour]
• Inlet x Outlet Sizes Available: 1/2 x 3/4 inch and 3/4 x 3/4 inch
• Voltage and Frequency: 120 Vac, 60 Hz
• Current Draw: 0.14A
• Minimum Regulated Capacity: 30 feet³/hour [0.8 meter³/hour]
• Maximum Regulated Capacity: 340-415 feet³/hour [9.6-11.8 meter³/hour]
