Resideo AMX101-UT-1LF 3/4 Inch Union NPT DirectConnect Mixing Valve Lead Free

Product Description

The Resideo Braukmann AMX101-UT-1LF is a high-efficiency, lead-free mixing valve designed specifically for simplified installation on water heater outlets. This product is engineered to provide consistent water temperature and increased safety against scalding, enhancing user comfort and system efficiency.

• DirectConnect design allows for easy installation without additional elbows or tees.
• Features a built-in proportional valve to control hot and cold water, ensuring constant temperature.
• Incorporates safety features such as flow reduction in seconds if the cold water supply is interrupted.

Product Highlights

Crafted from durable brass with Teflon-coated wear surfaces, the AMX101-UT-1LF meets rigorous standards including ASSE 1017 and is CSA & IAPMO listed. Ideal for residential heating applications.

Product Information

Standard Information

• Connection Type: NPT Union, 0.75 inches Bottom
• Temperature Range: 90°F to 130°F

Technical Specifications

• Pipe Size: 0.75 inches
• Operating Temperature Range (F): 90 F to 130 F
• Material: Brass, Stainless Steel
• Safety Certification: ASSE 1017, CSA, IAPMO
• Valve Action: Mixing
• Flow Capacity (Cv): 4
