Resideo AM100-1LF AM-1 Series 1/2 In. NPT Mixing Valve Lead Free

Product Description

The Resideo AM100-1LF AM-1 Series 1/2 inch NPT mixing valve is designed to maintain and limit hot water temperatures, providing both comfort and protection. This valve adjusts temperatures between 70 degrees Fahrenheit and 145 degrees Fahrenheit.

• Dual-purpose mixing and diverting valve
• Constant water temperature under changing conditions
• Maximum pressure of 150 psi

Product Highlights

The Resideo AM100-1LF ensures a constant water temperature regardless of changing operating conditions. It reduces flow within seconds if the cold water supply is interrupted, providing reliable performance and protection against scalding. The design includes a tamper-resistant feature with nickel-plated brass construction and EPDM O-rings for durability.

Product Information

Standard Information

• Brand: Resideo
• MPN: AM100-1LF
• Minimum Order Quantity: 1

Technical Specifications

• Connection Type: FNPT x FNPT
• Body Pattern: 3-Way
• Max Temperature: 145 degrees Fahrenheit
• Min Temperature: 70 degrees Fahrenheit
• Max Pressure: 150 psi
• Flow Capacity (Cv): 3.2
• Material: Nickel-plated brass
• Standards: ASSE 1017
