Research Products Corporation 500M Aprilaire 500M Manual Bypass Humidifier 12 gpd

Product Description

The Research Products Corporation 500M is a manual bypass humidifier designed for efficient humidity control. It delivers a water feed rate of 3 gallons per hour and an evaporative rate of 0.5 gallons per hour. This model operates at 24 volts and 0.5 amps, making it suitable for residential applications.

• Humidifies homes up to three thousand square feet.
• Incorporates a built-in damper and saddle valve for easy installation.
• Features a drain to remove excess minerals.

Product Highlights

This humidifier provides reliable humidity control with an automatic digital humidifier control for optimal performance in tightly constructed homes.

Product Information

Standard Information

• Type: Manual
• Series: 500

Technical Specifications

• Dimensions: 13 inches H x 15-5/8 inches W x 10-1/4 inches D
• Duct Size: 6 Inch Diameter
• Plenum Opening: 9-1/2 inches W x 9-1/2 inches H
• Nominal Capacity: 12 gallons per day
• Water Feed Rate: 3 gph
• Evaporative Rate: 0.5 gph
• Electrical Ratings: 24 V, 0.5 A, 60 Hz
