Reliance Worldwide Corporation PPSV501222W Straight Shut-Off Valve 3/8 x 1/4 in

Product Description

The RELIANCE WORLDWIDE CORPORATION PPSV501222W straight shut-off valve is designed for use with plastic or copper OD size tubings. Constructed with a polypropylene body and EPDM O-rings, this valve offers chemical resistance. It is suitable for potable water applications. Not intended for use with compressed air, explosive gases, or fuels.

• 3/8 x 1/4 in Nominal
• Push-Fit x FNPT Connection
• Lead-Free, Water Media

Product Highlights

This straight shut-off valve features a polypropylene body and EPDM/Polypropylene softgoods. It is suitable for use with plastic or copper OD size tubings.

Product Information

Standard Information

• Brand: RELIANCE WORLDWIDE CORPORATION
• Manufacturer Part Number: PPSV501222W

Technical Specifications

• Body Material: Polypropylene
• Connection Type: Push-Fit x FNPT
• Nominal Size: 3/8 x 1/4 in
• Seal Material: EPDM
• Softgoods Material: EPDM/Polypropylene
• Suitable For Use With: Plastic or Copper OD Size Tubings
• Temperature Rating: 33 deg F
• Lead-Free/Contains Lead: Lead-Free
• Media: Water
