Reliance Worldwide Corporation 23155-0045 EB45-U Single Union Threaded 1 Inches

Product Description

The Reliance Worldwide Corporation 23155-0045 EB-45 Series is a lead-free pressure reducing and regulating valve designed for safety and reliability. It features a bronze body and is suitable for both cold and hot water services up to one hundred eighty degrees Fahrenheit.

• Modular cartridge design for quick maintenance.
• Rugged bronze construction ensures durability.
• Compact design ideal for installations in tight spaces.

Product Highlights

This valve is essential for managing water pressure efficiently.

Product Information

Standard Information

• Type: Pressure Regulator
• Service: Water

Technical Specifications

• Connection Type: Single Union NPT
• Size: 1 inch
• Operating Temperature Min: 33 degrees Fahrenheit
• Operating Temperature Max: 180 degrees Fahrenheit
• Operating Pressure Max: 400 psi
• Overall Length: 6.17 inches
• Overall Height: 5.40 inches
• Body Material of Valve: Lead Free Bronze
• Factory Set: 45 psi
• Outlet Range: 10-70 psi
• Flow Configuration: Directional Arrow
• Nominal Size: 1 inch
• Top to Inlet Center: 4.35 inches
