Regal Rexnord STS1102R Century 1.0 HP Round Flange 56J Dual Speed Full Rate Pool Motor

Product Description

The Regal Rexnord STS1102R is a 1 HP dual-speed motor designed for pool and spa applications. It operates efficiently at two speeds of 3450 and 1725 RPM. The motor runs on 230 volts and features a 56J frame, making it versatile for various pump systems.

• Designed for efficient dual-speed operation.
• Has automatic overload protection for reliable safety.
• Constructed from rolled steel for durability.

Product Highlights

This motor is built to serve in different aquatic setups, ensuring smooth and effective performance.

Product Information

Standard Information

• Brand: Regal Rexnord
• MPN: STS1102R

Technical Specifications

• Horsepower: 1 HP / 0.125 HP (low speed)
• Speed: Dual (3450/1725 RPM)
• Voltage: 230 V
• Amperage: 7.0/2.3 A
• Service Factor: 1.5
• Frame: 56J
• Electrical Type: PSC
• Enclosure: ODP (Open Drip Proof)
• Phase: Single
• Rotation: CCWSE (Counterclockwise Shaft End)
• Material: Rolled Steel
• Mounting Type: C-Face
• Shaft Type: Threaded, Single
• Shaft Diameter: 5/8 inch
