REGAL REXNORD OTR1036 OEM Replacement Motor

Product Description

The REGAL REXNORD OTR1036 is a replacement motor suitable for various applications. This motor operates using single-phase power at 115 volts and 60 Hertz. With a sturdy 48 frame and open enclosure, it provides reliable performance. It includes automatic thermal protection for safety. Rated at one-third horsepower with a speed of 1075 RPM, it offers four distinct speeds. The permanent split capacitor design ensures efficient operation.

• Single-phase motor operating at 115V and 60 Hz
• 48 frame with open enclosure providing durability
• Rated for 1/3 HP with 4 speeds

Product Highlights

This motor is designed for effective use in air-over applications and is built for longevity and reliability.

Product Information

Standard Information

• Brand: Regal Rexnord
• MPN: OTR1036

Technical Specifications

• Phase: 1
• Output HP: 1/3 HP
• Input Voltage: 115 V
• Speed: 1075 RPM
• Service Factor: 1.0
• Frame: 48Y
• Enclosure: Open Enclosed
• Thermal Protection: Automatic
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 6.0 A
• Duty: Air Over
• Insulation Class: B
• UL: Recognized
• CSA: Y
• CE: N
• Number of Speeds: 4
• Electrical Type: Permanent Split Capacitor
• Starting Method: Across The Line
• Poles: 6
• Rotation: Counterclockwise Lead End
• Mounting: Resilient Rings
• Drive End Bearing: Ball
• Opp Drive End Bearing: Ball
• Frame Material: Rolled Steel
• Shaft Type: Flat
• Overall Length: 9.86 inches
• Frame Length: 3.63 inches
• Shaft Diameter: 0.500 inches
• Shaft Extension: 5.12 inches
