REGAL REXNORD H582V2 Century Motor 3/4 HP

Product Description

The REGAL REXNORD Century H582V2 is a 3/4 horsepower motor designed for industrial use, specifically for belt drive applications. This motor operates on a 3-phase, 60Hz power supply and is identified by its MPN H582V2. It features a dual voltage rating of 208-230/460 volts and has a rotational speed of 1725 RPM.

• 3/4 horsepower power output
• Operates at dual voltage: 208-230V and 460V
• Open Drip Proof (ODP) enclosure for protection

Product Highlights

The motor is designed with a 56H frame, making it suitable for a variety of mechanical power transmission systems. Its service factor of 1.25 indicates its reliability in different applications where water exposure is minimal. It incorporates Class B insulation, ensuring durability and efficiency.

Product Information

Standard Information

• Horsepower: 3/4
• Frame Size: 56H

Technical Specifications

• RPM: 1725
• Phases: 3
• Frequency: 60 Hz
• Voltage: 208-230/460 volts
• Amperage: 2.9/1.45
• Service Factor: 1.25
• Enclosure: ODP
• Insulation Class: B
