Regal Rexnord D913 Motor - 1/4 HP - 460V - 1075 RPM

Product Description

The Regal Rexnord D913 is a 1/4 HP motor designed for continuous air over applications. It operates at 460V and 1075 RPM and draws a current of 1.1A. This model features a rolled steel frame and ball bearings for reliable operation. Its versatile design allows for both horizontal and vertical installation. The D913 includes a 5 Mfd-370 Volts run capacitor and has a reversible rotation capability.

• Operates at 460V, 1075 RPM with a current draw of 1.1A.
• Features a 0.5 inch diameter shaft, suitable for both horizontal and vertical use.
• CSA certified for hazardous locations ensuring safety and reliability.

Product Highlights

Ideal for HVAC applications where continuous operation is essential. The motor's ambient temperature rating is 60°C, making it suitable for various environments.

Product Information

Standard Information

• Brand: Regal Rexnord
• Item Number: D913

Technical Specifications

• Horsepower: 1/4 HP
• Voltage: 460V
• RPM: 1075
• Current: 1.1A
• Frame: 48
• Construction: Rolled Steel
• Weight: 11.8 lb
• Ambient Temperature Rating: 60°C
