REGAL REXNORD D366 Motor - 1/14 HP, 115V, 1550 RPM, 2-Speed, 2-Shaft

Product Description

The REGAL REXNORD D366 is a fractional horsepower motor designed for air conditioning and various general applications. This motor operates at one hundred fifteen volts and provides one-fourteenth horsepower. It features a two-speed function, allowing for adjustable airflow and operational intensity. With a rotational speed of one thousand five hundred fifty RPM, it is suitable for moderate-speed requirements. This model has a double shaft design, enabling connections to components at both ends. The open air over (OAO) enclosure and sleeve bearings support the shaft during operations.

• Operates at one hundred fifteen volts and delivers one-fourteenth horsepower.
• Two-speed functionality for adjustable performance.
• Double shaft design for versatile connections.

Product Highlights

The REGAL REXNORD D366 is ideal for HVAC applications, providing reliable performance and flexibility in installation.

Product Information

Standard Information

• Manufacturer Name: Regal Rexnord - Fasco
• Product Number: D366

Technical Specifications

• HP: 1/14
• Volts: 115
• RPM: 1550
• Speed: 2
• Amps: 2.5
• Enclosure: OAO
• Shaft: Double Shaft
• Bearing: Sleeve Bearing
