REGAL REXNORD D251 Fan Coil Motor 1/15-1/35-1/50 Hp

Product Description

The REGAL REXNORD D251 is a shaded pole motor suited for fan coil, air conditioning, and heating unit applications. This motor, with a frame size of forty-two, features an open air over enclosure and thermal protection for enhanced safety and durability.

• Designed for fan coil, air conditioning, and heating units.
• Includes a double shaft of 0.5 inches diameter.
• Thermally protected with an open air over enclosure.

Product Highlights

This motor is effective in various HVAC applications, ensuring efficient operation in both heating and cooling systems.

Product Information

Standard Information

• Brand: REGAL REXNORD
• MPN: D251

Technical Specifications

• Phase: 1
• Output Power: 1/15-1/35-1/50 Hp
• Input Voltage: 208/230 V
• Speed: 1050 rpm
• Service Factor: 1
• Frame Size: 42
• Enclosure: Open Air Over
• Thermal Protection: Thermally Protected
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 1.2/0.5/0.4 A
• Duty: Air Over
• Insulation Class: A
• UL Listed: Recognized
• CSA Certified: Y
• CE Certified: N
• Number of Speeds: 3
• Electrical Type: Shaded Pole
• Starting Method: Across The Line
• Number of Poles: 6
• Rotation: Counterclockwise Shaft End
• Mounting Type: Resilient Base
• Drive End Bearing Type: Sleeve
• Opposite Drive End Bearing Type: Sleeve
• Shaft Type: Flat
• Overall Length: 20.85 inches
• Shaft Diameter: 0.5 inches
• Shaft Extension: 9.25 inches
