REGAL REXNORD D142 Ventilation Motor 1/15-1/25 Hp

Product Description

The REGAL REXNORD D142 is a fractional horsepower ventilation motor suitable for various applications. This motor features a 42-frame design and operates at 115V with a frequency of 60 Hz. It offers two speeds, reaching up to 1050 RPM. The motor has an open air over enclosure and uses shaded pole technology for its electrical type. It also includes sleeve bearings for efficient performance.

• Operates at 115V and 60 Hz, current rating at 2.6/1.6 A.
• Equipped with a 3/8 inch diameter shaft that includes flat and extended studs for easy mounting.
• Thermally protected ensuring safety during operation.

Product Highlights

This motor is ideal for air-over duty applications and is thermally protected to enhance its longevity and reliability.

Product Information

Standard Information

• Brand: REGAL REXNORD
• MPN: D142

Technical Specifications

• Phase: 1
• Output HP: 1/15-1/25 Hp
• Input Voltage: 115 V
• Frequency: 60 Hz
• Speed: 1050 rpm
• Current: 2.6/1.6 A
• Service Factor: 1
• Frame: 42
• Enclosure: Open Air Over
• Thermal Protection: Thermally Protected
• Ambient Temperature: 40 °C
• Duty: Air Over
• Insulation Class: A
• Poles: 6
• Rotation: Clockwise Shaft End
• Shaft Type: Flat
• Shaft Diameter: 0.375 in
• Shaft Extension: 2.47 in
• Overall Length: 5.25 in
