Regal Rexnord D1071 OEM Replacement Motor

Product Description

The Regal Rexnord D1071 is a reliable motor suitable for various industry applications. This unit operates on 208/230 volts and achieves a speed of 1100 RPM. Designed with a 42 frame size and an open air over enclosure, it includes automatic thermal protection to ensure safety during operation.

• Operates at 208/230V and 1100 RPM
• 42 frame size with open air over enclosure
• Ball bearings and 1/2 inch diameter shaft

Product Highlights

This motor is built for consistent performance in demanding conditions.

Product Information

Standard Information

• Manufacturer Part Number: D1071
• UPC: 815585027898

Technical Specifications

• Output HP: 1/6 Hp
• Output KW: 0.13 kW
• Voltage: 208/230 V
• Speed: 1100 RPM
• Frequency: 60 Hz
• Phase: 1
• Service Factor: 1
• Frame: 42
• Enclosure: Open Air Over
• Thermal Protection: Automatic
• Ambient Temperature: 40 °C
• Current: 0.99 A
• Duty: Continuous
• Insulation Class: B
• UL: Recognized
• CSA: Y
• CE: N
• Number of Speeds: 3
• Electrical Type: Permanent Split Capacitor
• Starting Method: Across The Line
• Poles: 6
• Rotation: Reversible
• Mounting: Extended Studs
• Drive End Bearing: Ball
• Opp Drive End Bearing: Ball
• Frame Material: Rolled Steel
• Shaft Type: Flat
• Overall Length: 6.02 inches
• Frame Length: 3.38 inches
• Shaft Diameter: 0.500 inches
• Shaft Extension: 2.2 inches
